16 Channel TVR with HDMI 1080p Output (No HDD)

Model: D16TVI-A-V2
Our Price: Members Only
Hurry up! only left
Product Details
16 Channel TVR with HDMI 1080p Output (No HDD)

This 16 Channel TVR is full of features with a great form factor. With an easy, intuitive graphical user interface and the support of many browsers. The D16TVI-A-V2 can support TVI and IP cameras. Check out the Technical Specifications tab for the many features this unit has to offer and give us a call for any help you need prior to installation and of course any help you may need during and after your installation.

NOTE: When using IP cameras they connect to your network not directly to the TVR. You can power IP cameras with normal power solutions but if you want to power by POE then a separate POE switch would be needed for the IP cameras.

Installation Note: We are aware of an issue where the ZUUM TVR when installed on a network with DIRECTV and Genie's that there may be a network conflict and cause the DIRECTV Genies to be knocked off the internet. Call Tech Support for options to correct this issue.







ZUUMDVR iOS APP FREE Mobile App for iPhone on the Apple APP Store (vssmobile can be used as well)





ZUUMCCTV APP FREE Mobile App for Android on Google Play (vssmobile can be used as well)
  • 16 Channel TVR with HDMI 1080p Output
  • Supports TVI 2.0 and IP cameras
  • Embedded Linux operating system, H.264 High Profile@Level4.2
  • Display resolution 1080p(25/30fps), 720p(25/30/50/60fps), 960H, D1
  • Recording resolution 16ch. HD-TVI 1080p@15fps, 16ch. 720p@30fps
  • Recording resolution for IP cameras up to 8Mbps
  • Remote access by IE, Firefox, Safari up to El Capitan, CMS and Mobile Client iOS and Android App
  • Supports talk back
  • HDMI, VGA and BNC output at the same time
  • Audio input 1 / Audio output 1
  • Pentaplex Operation
  • Control TVR by APP remote feature
  • 1 SATA port, Up to 8TB
  • Backup Modes USB, HDD, Network Backup
  • 10/100 network interface
  • 2 USB 2.0 ports
Resources
Documentation

V2 Instruction Manual

DDNS Quick Start Guide

USB Firmware Upgrade Instructions


Videos

Comcast Router Port Forwarding

AT&T 2Wire Router Port Forwarding

Zuum DDNS (Setup a Free Hostname)

IMS300 for Windows

Download Playback Video by Windows IE

Drivers

ZUUM TVR 60616 Control 4 Driver


Software/Firmware

IMS300 (CMS) for Windows 10

IMS300 (CMS) for Mac OS Sierra

Media Player (Used to play .dav files or convert them to MP4)

DVR/IP Camera update tool with instructions

D16TVI-A-V2 Firmware V4.1.2.6 (20180110)



Tech Specs
Model No: D16TVI-A-V2
System
Operating System Embedded Linux
Pentaplex Operation Live monitoring, recording, playback, backup and remote access
Control USB mouse, Network, APP Remote
Video & Audio
Video Input 16channel BNC (1Vp-p, 75Ω)
Up to 8channel IP input up to 6Mbps
Video Output 1 HDMI 1.3a 1920x1080 resolution, 1 VGA 1920x1080, 1280x1024, 1366x768, 1280x720, 1024x768, resolution, 1 CVBS BNC(1.0Vp-p, 75Ω)
Audio Input 1ch. RCA (Line in, 2Vpp, 1KΩ)
Audio Output 1 RCA (line out, 2Vpp,300Ω) Two-way Talk
Display
Display Resolution 1080p(25/30fps), 720p(25/30/50/60fps), 960H, D1
Tour Display
 Support
Privacy Masking Four zones for privacy masking for each channel
Recording
Video Compression H.264
Audio Compression G.711A
Image Encoding Adjustable encoding quality, variable stream/fixed stream
Max Compression Ability
 16ch. 1080p@15fps, 16ch. 720p@30fps
IP camera up to 8Mbps
Recording Mode Manual, auto, motion detection, stop
Video Detection & Alarm
Trigger Events Recording, PTZ, Tour, Email
Motion Detection 396 (22x18) detection zone, variable sensitivity levels
Capture JPEG Capture
Alarm Input N/A
Alarm Output N/A
Playback & Backup
Sync Playback
 Up to 16ch. Playback up to 1080p
Backup Mode USB, HDD, Network Backup
Network
Ethernet
 1 RJ45 port (10/100M)
Network Protocol TCP/IP, UDP, HTTP, RTP/RTSP
Network Functions DHCP, PPPOE, DDNS, SMTP, SNTP, FTP, UPnP, P2P, 3G
Remote Operation Monitoring, PTZ control, playback, system settings, file download, log information
Remote Client IE Browser, Mobile App, CMS, Firefox, Safari
Mobile Device iPhone, iPad,Android
USB Interface 2 USB 2.0 ports
Serial Interface N/A
Storage
HDD Support 2 SATA port (Max 8TB)
HDD Management Hard disk hibernation technology, HDD faulty alarm
Environment
Power Supply 12VDC 3.3A
Power Consumption 10watts (without HDD)
Temperature Operation: 14 to 131°F
Humidity 10 - 90% RH
Dimensions - Inches 12.59"(w) x 1.89"(h) x 9.68"(d)
Weight - lbs 4.40 (without HDD)
Enclosure Metal case
