16 Channel TVR with HDMI 1080p Output (No HDD)
NOTE: When using IP cameras they connect to your network not directly to the TVR. You can power IP cameras with normal power solutions but if you want to power by POE then a separate POE switch would be needed for the IP cameras.
Installation Note: We are aware of an issue where the ZUUM TVR when installed on a network with DIRECTV and Genie's that there may be a network conflict and cause the DIRECTV Genies to be knocked off the internet. Call Tech Support for options to correct this issue.


FREE Mobile App for iPhone on the Apple APP Store (vssmobile can be used as well)
FREE Mobile App for Android on Google Play (vssmobile can be used as well)
This 16 Channel TVR is full of features with a great form factor. With an easy, intuitive graphical user interface and the support of many browsers. The D16TVI-A-V2 can support TVI and IP cameras. Check out the Technical Specifications tab for the many features this unit has to offer and give us a call for any help you need prior to installation and of course any help you may need during and after your installation.




- 16 Channel TVR with HDMI 1080p Output
- Supports TVI 2.0 and IP cameras
- Embedded Linux operating system, H.264 High Profile@Level4.2
- Display resolution 1080p(25/30fps), 720p(25/30/50/60fps), 960H, D1
- Recording resolution 16ch. HD-TVI 1080p@15fps, 16ch. 720p@30fps
- Recording resolution for IP cameras up to 8Mbps
- Remote access by IE, Firefox, Safari up to El Capitan, CMS and Mobile Client iOS and Android App
- Supports talk back
- HDMI, VGA and BNC output at the same time
- Audio input 1 / Audio output 1
- Pentaplex Operation
- Control TVR by APP remote feature
- 1 SATA port, Up to 8TB
- Backup Modes USB, HDD, Network Backup
- 10/100 network interface
- 2 USB 2.0 ports
Resources
Documentation
V2 Instruction Manual
DDNS Quick Start Guide
USB Firmware Upgrade Instructions
Videos
Comcast Router Port Forwarding
AT&T 2Wire Router Port Forwarding
Zuum DDNS (Setup a Free Hostname)
IMS300 for Windows
Download Playback Video by Windows IE
Drivers
ZUUM TVR 60616 Control 4 Driver
Software/Firmware
IMS300 (CMS) for Windows 10
IMS300 (CMS) for Mac OS Sierra
Media Player (Used to play .dav files or convert them to MP4)
DVR/IP Camera update tool with instructions
D16TVI-A-V2 Firmware V4.1.2.6 (20180110)
DDNS Quick Start Guide
Videos
AT&T 2Wire Router Port Forwarding
Drivers
ZUUM TVR 60616 Control 4 Driver
IMS300 (CMS) for Mac OS Sierra
Media Player (Used to play .dav files or convert them to MP4)
D16TVI-A-V2 Firmware V4.1.2.6 (20180110)
Tech Specs
Model No: | D16TVI-A-V2 |
System | |
Operating System | Embedded Linux |
Pentaplex Operation | Live monitoring, recording, playback, backup and remote access |
Control | USB mouse, Network, APP Remote |
Video & Audio | |
Video Input | 16channel BNC (1Vp-p, 75Ω)
Up to 8channel IP input up to 6Mbps |
Video Output | 1 HDMI 1.3a 1920x1080 resolution, 1 VGA 1920x1080, 1280x1024, 1366x768, 1280x720, 1024x768, resolution, 1 CVBS BNC(1.0Vp-p, 75Ω) |
Audio Input |
1ch. RCA (Line in, 2Vpp, 1KΩ)
|
Audio Output |
1 RCA (line out, 2Vpp,300Ω) Two-way Talk |
Display | |
Display Resolution |
1080p(25/30fps), 720p(25/30/50/60fps), 960H, D1 |
Tour Display |
Support |
Privacy Masking | Four zones for privacy masking for each channel |
Recording | |
Video Compression | H.264 |
Audio Compression | G.711A |
Image Encoding | Adjustable encoding quality, variable stream/fixed stream |
Max Compression Ability |
16ch. 1080p@15fps, 16ch. 720p@30fps IP camera up to 8Mbps |
Recording Mode | Manual, auto, motion detection, stop |
Video Detection & Alarm | |
Trigger Events | Recording, PTZ, Tour, Email |
Motion Detection | 396 (22x18) detection zone, variable sensitivity levels |
Capture | JPEG Capture |
Alarm Input | N/A |
Alarm Output | N/A |
Playback & Backup | |
Sync Playback |
Up to 16ch. Playback up to 1080p |
Backup Mode | USB, HDD, Network Backup |
Network |
|
Ethernet |
1 RJ45 port (10/100M) |
Network Protocol | TCP/IP, UDP, HTTP, RTP/RTSP |
Network Functions | DHCP, PPPOE, DDNS, SMTP, SNTP, FTP, UPnP, P2P, 3G |
Remote Operation | Monitoring, PTZ control, playback, system settings, file download, log information |
Remote Client | IE Browser, Mobile App, CMS, Firefox, Safari |
Mobile Device | iPhone, iPad,Android |
USB Interface | 2 USB 2.0 ports |
Serial Interface | N/A |
Storage | |
HDD Support | 2 SATA port (Max 8TB) |
HDD Management | Hard disk hibernation technology, HDD faulty alarm |
Environment | |
Power Supply | 12VDC 3.3A |
Power Consumption | 10watts (without HDD) |
Temperature | Operation: 14 to 131°F |
Humidity | 10 - 90% RH |
Dimensions - Inches | 12.59"(w) x 1.89"(h) x 9.68"(d) |
Weight - lbs | 4.40 (without HDD) |
Enclosure | Metal case |
